The last time the computer was assigned to the Tucao is not light, the landlord I still strong to withstand, there is my wonderful plan with the machine, after buying the accessories plan to buy the chassis, the results of the cup with the chassis in the discovery phase are used No, the earliest phase is this: The original power supply power is relatively small, if not enough to use the first to scouring a silver Xin SX500-LG, the result depth 130 can not use P115EA, fancy another found that the video card may not fit: Well, long time no toss, then toss a back, their own DIY, I am me, so wayward I, just for such a simple idea, spent more than half a month before and after, the size of the above reference Lianli's Ncase M1 ITX has a finished size of 170x240x320, full backplane structure, full-size graphics card support, and up and down ventilation. It is hoped that the top chassis will not have good heat dissipation. The heartbeat is not as good as the action. When the idea has been established, the design is started. As a result, the original CAD software WIN10 cannot be used, and it has to be downloaded and installed again. The following tool software also encounters this problem. The most important engraving machine has been for several years. Did not touch, once gave up the plan. After giving up and being a little indifferent, after several repeated attempts, he persisted in his own, DIY works. The appearance of the above is also not likely to be too complicated. The whole shape is a straight up and down cube. The following is Draft CAD drawing: You can see that the actual drawings are six, because they are not doing this, and there is no relevant size can refer to, all the size of their own according to the old chassis and bought accessories slowly measure and calculate, took a long time After completion, the quantity and quantity were counted, and after all, there were minor mistakes in the front and rear panels, which led to a re-production, and the cost increased a lot. All the materials were purchased in Taobao, I will not be on the price The main material 2mm 4mm aluminum plate, bought a total of 150 + to spend the appearance of the state, the front panel 4mm, the other is 2mm, after the completion of the overall steel in line with expectations Skeleton 15X15 profile, forgot to take photos, cut down one place directly, used four, and played the role of connecting each facade Front USB3.0, audio, microphone interface, originally intended to use the old chassis, but the interface is still a bit behind the 2.0, and spent a few more than 30 dollars Screws to be used in the chassis, bought two kinds of stainless steel and black treatment, all the internal stainless steel screws Boot button, buy 12mm with indicator light, Taobao also have to buy the finished product, the price is more expensive, direct removal of the old chassis of the line of their own welding, red and blue to buy one, outside the last time used to complete the car's velvet tape package It's OK. 30mm foot feet No material at home, directly bought finished products, O-rings sticking up old, fainted Sideways had planned to use toughened glass. Taobao asked several of them that they did not care about me. Well, if they ignore it, they ignore it. They have ordered two pieces of plexiglass. They are already on the road, and they have gone to more than 40. Wonderful enough, the entire computer is not a piece of light pollution, but also made it into a double-sided side through. The main thing is to buy the above, the others are able to demolition of the old demolition of the old, there is the previous inventory of the time playing engraving machine, the entire material procurement probably spent 250 + (including the aluminum plate which bought more after mistakes) , Drawings are in place, materials are in place, and the chassis is slowly started Because of the need to use engraving machines, CAD drawings, the latter is the production of a variety of knife, a long time did not play this stuff, and re-familiar and spent a little time, before and after the production of dozens of knife, heart ah Antique computer runs MACH3 The first piece completed was the backplane. The mounting hole was in the correct position and the alignment holes were suitable. Once successful, it gave a great deal of confidence. Originally, the alignment hole was on the apron and no suitable one was found. After the backplane is hollow, I would like to change the radiator and install the M2 SSD directly. The opening size is just right. Front and rear panels, the front panel was originally intended to be made into a flat, looking too simple, then carved a trapezoidal groove to increase the three-dimensional sense, we feel like? On the top cover, a hole is punched, while facing the power inlet, while on the top of the main board, the hole of the main board can be installed with 120 water cooling if necessary. So many years have not been played in this month. Many The ancient method of bending, originally wanted to get outside to processing, think about it, in the design of the size of the open V-groove, two pieces of wood clips, a pull, perfect solution to the problem of folding. The lower cover is also similar Sheet metal fittings, a piece of power fixed board, the bottom opened a double 120 fan hole, only to find the last, not the standard thickness, the video card is only 22mm from the bottom, but fortunately found a thin buy under Taobao, It also solves a heart disease I did my own internal power cord, Taobao did not find a lap to find a finished product, it is estimated that my search keyword is not accurate, had no choice but to self-reliance, and the power cord old chassis with a 90 turn line, used here just right, Before the socket was used to play with the engraving machine, please ignore my slag solder joints, put on the heat-shrink tubing, and let the hair dryer do everything. All spare parts here are ready, not far from success Begin assembly, skeleton, backplane, front and rear panels installed first, really need to fine-tune the installation process, but fortunately aluminum is relatively soft, a sickle all get, for example, the backplane, when the graphics card installed only found backplane that less A gap, double-card video card fixed board grows, will be topped to the backplane The power fixing board, originally afraid of 2mm is not thick enough, the result is because the fixed board span is relatively small, rigidity is completely no problem Self-welding internal power cord Look at the power supply position, limited by the length of the original line, the power is a bit on the front, in fact, can also be turned into a 90 degree M1 installation, like that theory can be said on the 240 can be cold row, cold row Too expensive, still do not toss, and now the power supply position can only support graphics cards within 300, later talk about it When the front USB port and the start button are installed, it is found that the home can't find a single M3 nut. Fortunately, immediately, D has two of them and solves the problem smoothly. Chassis assembly to the above is also almost finished, the chassis from the beginning of the design on the route will probably have a direction, so basically did not take any detours, because it is the original line, many lines or a long point, slightly lacking, Look at the toss finished the chassis, is not in the tossing under the custom line, a total of more than a dozen black tie, self-feeling pass is still pass it The benefits of a full backplane are perfect here, and they are all blown by themselves. Are there any and no? The original line is this kind of flat line. It is not very good for the line and it is completely torn. The back of the line: 24P, 4P line directly from the power supply line below the hole around the backplane in the winding back (a good expression of ah), the original wiring will not be able to be short, the blue is the front USB3.0 Wiring, the line is too long, can only be so a circle, and the finished thing is really bad deal, but fortunately it is not difficult to see, the following small bar is the line of the hard disk data cable and computer start button, the picture above is not clear Overall, it's okay to see it. It may be a lover’s eye, and his own child looks so beautiful. It was originally planned that the two 2.5-inch hard disks should be installed on the backplane. As a result, the chassis was assembled and the cups were found to have fewer nuts for the profiles in the figure below. The hard disks were temporarily moved to the bottom of the chassis. The fan could not be installed, miserable Front alignment: SX500-LG's 4P interface cable has two I directly tied together, the original line length is too long, short too short, 4P even a few short mm are not inserted, from top to bottom, respectively 4P line 24P line start key line USB front port line, its own line is relatively hard, folded line is not straight enough, leading to a good line of chaos, in order to further beautify can only look on the custom line . The graphics cable is long, long, long, and tried a lot of times before using a few straps to tie it up. It looks neat, and the extra lines plug the back of the power supply. Hard disk above mentioned under the installation, to Ye Hao, all the lines all under the graphics card, the eye is not seen for the net I had previously organized several computers and I had never thought about the line. The whole line was so carefully used that all my friends were bad. After 20 days of hard work, the first time the DIY chassis has been completed, the first time, I believe it should be the last time, many things toss once is enough, after all, from the time, energy, cost, It is better to buy finished products directly. This toss is a kind of belief and a feeling. Front of the chassis, the overall use of 4mm aluminum cutting, the initial idea was made bayonet type, the results found in Taobao above a large circle did not find a suitable bayonet to buy, no way to directly use a simple and crude screws Fixed, the plan is to use the hexagon socket countersunk head screws, and found that they need to buy tools, forget, they have not used so much to pay attention to Chassis chrysanthemum reserved 8-9cm fan position, seat and other double 11, fan is a good price Positive 45-degree angle, watching there is a kind of The main side through the surface Double 11 have to go to Amoy CPU radiator, or else the chassis looked a little empty ah, up and down black taped tape, mainly to separate the aluminum plate with organic glass There are a lot of holes in the top vent hole. I hope it is useful for heat dissipation. It is estimated that many friends do not like this type of punching Front USB and start button (please ignore the black screws) USB hole out of a small problem, according to the size of the buyer to open, the seller is the result of the net size of the parts, but also spent a lot of manual In order to save money? It seems that the goal of saving money and tormenting people has not been achieved! It takes a lot of time, effort, and cheaper prices than finished products. Everything is fulfilled and fulfilled after completion! Do you like to DIY? The process is basically smooth, but here the DIY of the chassis can only be used. Surface treatment, chassis cooling, etc. have a long way to go. You wait, see you next time. The end of the computer desktop, the small chassis above the desktop is harmonious, ah, the actual effect of the following photos did not reflect. There should be a plan behind it that will take care of the entire desktop and take care of the mess on the table. At the end of the month, how are you worthy of your broken silver? 8K HDMI Cable, HDMI 2.1 48Gbps High Speed Nylon Braided HDMI Cord with eARC HDR10 4:4:4 HDCP 2.2&2.3, 4K HDMI Cable Compatible with Dolby Atmos Apple Fire LG Samsung TV PS5 PS4 Switch Xbox Roku.
